Product introduction

Typical installation

The induction lamp is used in the most advanced human body infrared detection sensor, built-in temperature compensation circuit and power supply voltage regulator control circuit. Through the optimization of the whole circuit design, the components with high quality, high precision materials, induction stability, reliable work, is our first LED induction lamp.

Two, product features

1 the use of a new type of high efficiency white LED Technology: with high efficiency, power saving, long life, energy saving, environmental protection, explosion-proof, cold light, suitable for all kinds of places to use.

2 the use of advanced human thermal infrared detection sensor technology, with high sensitivity, anti-interference, fast response.

3 people come to light, people go off: the optimization of the induction control design, to achieve people to light, automatic delay.

4 built in light sensing devices, automatic recognition of the day and night status, automatic standby during the day, night light.

5 humanized appearance design, exquisite appearance, fashion, thin, aluminum alloy shell.

6 reasonable structural design, clever hidden fixed, installation without screw.

Three, product specifications

1 induction way: human body infrared induction

3 induction distance: >3 meters

4 induction angle: 120 degree

5.LED life: more than 80 thousand hours

6.LED brightness: 0.5W

7 Color: White / warm light (optional)

8 operating current: 120 mA

9 battery power: 4 AAA batteries or rechargeable batteries

10 delay time: 15 seconds

12 lamp temperature: -10~50

13 product size: long 190mmX wide 30mmX thick 16mm

14 weight: 100 grams (without batteries)

Four, product installation method

1 double-sided adhesive paste

2 magnetic base

Five, matters needing attention

1, the lamp is built with photosensitive components, so the daytime environment may not work; the user needs to adjust their work mode.

2, it is recommended to use 555, Nanfu, super GP, alkaline batteries, alkaline batteries with high performance quality. Ordinary battery may appear to reduce the standby time.

4, the working environment temperature should be between -5 degrees C~40 degrees C, beyond the range of this temperature will be a false trigger, or the battery power consumption is likely to increase.

5, the light is not waterproof, do not place in the rain, severe humidity, light and other environmental changes.

6, the induction lamp does not place in the window, the temperature or the light changes obviously place, otherwise it may produce the false action.

Six, the scope of application

Door, attic, dark room, basement, garage, cellar, bar table, wardrobe, cabinets, cupboards, bookcases, hotel wardrobe, safe deposit box, tents, car luggage compartment after the end of the
