Model: 0405

technical parameter

1 induction way: using micro vibration sensor

2 induction control: built-in micro vibration processing chip

Number 4: 3.LED lamp

4.LED life: more than 80 thousand hours

5.LED brightness: 1400-1600MCD/, light emitting angle: 120 degrees /30 degrees

6.LED light color: white

7 the standby current: 70 a

8 machine operating current: 70 Ma

9 power: 3 AAA alkaline batteries

10 luminous delay time: 20 seconds

11 product application environment temperature and humidity: -40 degree 5%-93% degree -5

12 product size: 220 x 23.7 x 18.3, unit: mm

13 storage temperature: -10 degree -40 degree

14 weight: 60 grams (without batteries)

Product installation method

1, self tightening support

2, double-sided adhesive paste

3, fixed plastic screws

Remarks

1, led to the delay of the time is to detect the induction lamp has left the induction area, will continue to glow after 5-7 seconds automatically put out the lights of the time.

2, induction time interval is refers to the induction light, the light goes out, will keep the 5-6 second time does not accept the induction, this time is called the induction time interval. The time interval is short, the induction degree of stability is lower. After repeated experiments, it is concluded that the interval 5-6 seconds is the best parameter.

3, the boot self test time is the first time to refer to the induction lamp or re install the battery, it takes about 20 seconds to stabilize the working circuit time.

Application occasions;

1 bedroom: with it, no longer a bed to turn off the headlights. Get up at midnight, a body can be light, convenient power!

2 Restroom: do not frequently switch headlights, get away with lights, will automatically turn off the lights to save electricity.

3 home power: with it, cooking, eating as usual.

4 students are good partners, no electricity, no learning error; the bedroom to wake up at night it will not affect the others.

5 friends gathering, outdoor camping, PARTING and other activities of a good helper. Light and compact is an ideal auxiliary light source.

6 can be installed in the aisles, corridors, staircases, wardrobe, closet, basement, without 220V wire cloth.

7 installed in the depot, warehouse, material or should not use 220V alternating current local factories, low safe voltage, safe trouble.
