First, product overview

This series of products is based on the non - polar dimming technology, through the small remote control lamp to achieve the switch, brightness. The lamp can be installed at any power outlet at will. The product is stable and reliable, energy saving and environmental protection, can be applied to the hall, room, kitchen, bathroom, corridor and other locations!

Two, product parameters function

1, input voltage: 90 -220V

2, power supply voltage: 5V

3, the key working voltage: 12V DC

4, rated power: 6W

5, standby current: 10mA

6, working temperature: -10 - 60

7, remote control distance: >30 meters,

8, remote control point of view: 360

9, the number of control can reach more than 100 thousand times

10, the use of digital coding technology, to achieve a machine a code

Three, operation instructions:

1, switch

In the off state, click or press the remote control lights, i.e.

2, adjust brightness

To turn off the lights or turn on the lights in length according to the remote control can adjust the light brightness, release the button lock brightness, the next light will automatically remember the brightness
